BREAKDOWN Rotary Wagon Tippler Repair & 3D Scanning Removal & Repair of Tippler Guide Wheels: New Vesconite Bushing – (temporary option) New EN19 “T” Shafts c/w Grease Groove Arrangement Refurbish Guide Wheels – Machine ID & OD Concentricity and Face...
Rotary Granulation Kiln Repair • All Static Grizzley Grates had to be removed, window patch cut on side of Kiln.• Retention Ring plate 20mm removed and replaced with new Retention Ring.• All Static Grizzley’s reinstalled and bolted into position, 120 off M20 holes...
On-Site Machining:• 10” & 12” Raised Face Flange Facing• Finish attained (Ra 3.2µm-CLA 125µ”) (Rz 12.5µm-500µ”)OTHER SERVICES WE OFFER Site Maintenance & Repairs Engineering Design Structural & Fabrication Machining Drives Project Financing The CSS...
Boiler Repair (In-Situ) Situ Boiler Repair• Outside Diameter – 57.2mm.• Wall Thickness – 4mm.• Material – P235GH.• Type of Weld – SMAW Repaired in Situ.• Welding Media – LH 2.5mm[dnxte_masonary _builder_version="4.21.0" _module_preset="default"...
Servicing done on main fans: • Removing casing.• Removing & replacement of fan.• Removal of fan drive motor and installation of new motor c/w laser alignment of couplings.• Remove damaged Inlet eye and replace with new inlet eye and verify clearance between...
CREDITSBy CSS Engineering Welding Quality Management CSS Engineering are registered and certified on the ISO3834-2:2021 management system through CertX SA (Pty Ltd). Our welders are highly qualified in welding processes namely ISO 4063 – 111(MMA), 141 (TIG), 131...
Core Drilling & Grouting Base Plates Core Drilling & Chemicals:• 8 off holes 62mm diameter x 1000mm deep.• 32 off holes 34mm diameter x 250mm deep. Levelling & Grouting:• Levelling/alignment, Shutter & Grouting of 2 off (2408mm x 549mm x 40mm thick)...
Primary Kawasaki Gyratory Crusher & Apron Feeder Recondition 1. Complete Gyratory Crusher Recondition – (4000ton per hour throughput):• Replacement of Bushes:o New Inner Eccentric Bush.o New Outer Eccentric Busho New Spherical Bearing Bush.o New Thrust Bearing...
3D Scanning Ball Mill for Relocation• Holding down points on existing plinths identified and plotted onto new plinths.• Mill retention angle from supply to discharge identified.• Helix Angle & Pressure Angle on Pinion Gear identified.• Angle relative to Pinion...
Remove, Repair, Install & Commission Iron Ore Reclaimer: • Manufacture Completely New Bucket Wheel Body.• Replace all Side Rollers on reclaimer structure.• Replace all Top Traveling Wheel Assemblies on reclaimer structure.• Repair / Replace all Feed and...
